Bunker Hill Announces Updated Mineral Resource and Identifies New Silver Exploration Targets
- Previous 8.8Mt Inferred resource significantly upgraded, supporting the rapid restart program:
- Indicated resource of 4.4Mt containing 3.03Moz of silver, 487M lb of zinc, and 176M lb of lead
- Inferred resource of 5.6Mt containing 8.3Moz of silver, 548M lb of zinc, and 312M lb of lead
- UTZ added new resource with successful silver exploration drilling
- The PEA remains on track for completion in early Q2-2021
- New, near surface silver exploration targets to be evaluated in current drilling campaign
TORONTO, March 19, 2021 (GLOBE NEWSWIRE) -- Sam Ash, CEO of Bunker Hill Mining, stated: “We are excited to see the results of our drilling campaign and continued digitization realized in this significant upgrade of the resource at Bunker Hill, building on the maiden resource we published less than a year ago. This demonstrates the mine’s outstanding mineral potential, which we expect to be reflected in the PEA assessing a rapid restart. This remains on track for delivery in early April. As part of the on-going campaign to add more silver to our resources, we have also identified some exciting new silver exploration targets in the upper levels of the mine which will be evaluated by drilling over the next few weeks”.TORONTO, Canada, March 19, 2021 – Bunker Hill Mining Corporation (the “Company”) (CSE: BNKR) is pleased to report a significant resource increase at Bunker Hill Mine located in Idaho’s Silver Valley, USA. This underpins the Preliminary Economic Assessment (“PEA”), aimed the mine’s rapid restart potential, due to be published in early Q2-2021.
The on-going digital modernization program has yielded a three-dimensional model, defining nearly 100 years of mining voids and geology, which increases confidence in the estimation of mineralization. Additional drilling, modern data collection and assaying, quality assurance and quality control protocols, as well as the verification channel sampling program of 2020 has provided the necessary information to increase the confidence and classification of the Newgard, Quill and UTZ mineral resource estimates. The preponderance of data has converted approximately seventy-seven percent (77%) of the Bunker Hill Mineral Resource to the Indicated Mineral Resource category.
The Bunker Hill Mineral Resource, effective March 19, 2021, reported at a zinc cutoff grade of 3.3% is described below:
|Bunker Hill Resource Table
|Zinc Resources||K Tons||Pb%||Ag opt||Zn%|
|Lead-Silver Resources||K Tons||Pb%||Ag opt||Zn%|
|Total Resources||K Tons||Pb%||Ag opt||Zn%|
Mineral Resources are reported at a zinc cutoff grade of 3.3%. Mineral Resources are not Mineral Reserves and do not have demonstrated economic viability. Mineral Resources are reported in situ and undiluted. Mineral Resources meet the reasonable prospects of eventual economic extraction due to the fact that the entire vertical extents of the mineralization have been developed on mining levels every two-hundred feet. Newgard and Quill were being actively exploited and developed prior to the shutdown of mining operations in 1991. High grade capping was applied to the assays prior to grade estimation. Grades are estimated using Inverse Distance Cubed (ID3) interpolation techniques. Grades were estimated into a regularized 5 ft x 5 ft x 5 ft block model. A bull density of 11.3 cubic feet per ton was applied to the entire mineral resource based upon historic density values from production records at Bunker Hill. Two-hundred sixty-one (261) drillholes, totaling 29,380-feet, containing 5,720 Pb, Zn and Ag assays were used in the determination of mineralization. Assays were composited to 4,483 5-foot composites. Additionally, 4,545 historic production car samples and 394 channel sample verification samples were used for the resource estimate. Historic mining voids, stopes and development drifting have been accounted for in the resource estimate.
Figure 1: Oblique View of UTZ, Newgard and Quill Mineral Zones Showing Indicated and Inferred Mineralization
Significant New Silver Exploration Target Identified
New interpretation and analysis based on developments in the geologic model have identified an exciting new silver exploration opportunity in the hanging wall of the Cate Fault in the upper areas of the Bunker Hill Mine.
Silver production at Bunker Hill came largely from discrete Galena-Quartz Veins that formed ore shoots hosted in preferable quartzite beds of the Revett formation. The vein segments are bounded by large normal faults such as the Dull, Kruger and Sullivan Faults, which have down-dropped large blocks of the stratigraphy and veins down to the south, with >4000 ft of collective displacement. The more recent Cate Thrust Fault has then bisected this package of rocks, shifting rocks above the fault >500 ft up to the north.
The 3D modeling has allowed Bunker Hill geologists to project these vein segments back to their position at time of emplacement. The presence of high-grade silver veins such as the historically mined Sierra Nevada Vein in the hanging wall of the Cate Fault demonstrate that the width of the mineralizing system has not been discovered and the southern margin is unknown. The similar grades, thickness and mineralogy of the vein segments across the earlier normal faults shows that the vertical extent of the system was likely at least 4x the down-dip length of the individual veins. A similar set of normal faults, such as the Buckeye Fault, with significant down-to-the-south displacement also exists in the hanging wall of the Cate fault, with Ag-Pb-Zn mineralization indicated by historic and recent drilling in the hanging wall, or down-dropped portions of these faults.
Figure 2: Hanging Wall of Cate Fault
To summarize, none of the major faults that were historically thought as controlling ore emplacement actually bound the mineralizing system, and the entire Property is fully within the elevation and mineralogical zonation leading to silver, lead and zinc deposition.
The Cate Fault was the limit of most early mining in the upper parts of Bunker Hill, and it wasn’t until the 1960’s that it was recognized as having post-mineral offset. A few of the first core holes ever drilled in Bunker Hill in 1898 from the 5 Level were directed past the Cate and Buckeye Faults, with impressive results including 12’ @ 42.7% Pb and 18.6 opt Ag in DH-4, but mining largely shifted to below the 9 level after the Kellogg Tunnel was completed, and these holes were never followed up on. Bunker Hill is currently drilling to test these targets, and the holes are intersecting encouraging structures and lithologies similar to what has been modeled. Any mineralization encountered in these holes will be an entirely new vein system for Bunker Hill, not defined, named, mined or incorporated in any prior mine plans or resource estimates. Drill holes have been planned to systematically offset any successful intercepts in the first holes, and drill stations are being prepared to test these targets at appropriate angles and reduced distances. The locations of the targets are such that any mineralization defined with successful drilling could be rapidly incorporated in an update to mine plans or mineral resources.
Figure 3: Planned Drill Holes from 5 Level at Cate and Buckeye Faults
Note: The reader is cautioned that these are exploration-stage targets, which is speculative in nature, and there is no guarantee of positive drill results defining any economic mineralization.
A video summarizing the digitization process can be viewed at the following link https://youtu.be/8X3FrWfbGl4?t=229 . In addition, further information is available on our newly launched website.
Recent drill results are presented in the tables below.
|7046||From||To||M||ZnEq (%)||g/t Ag||%Pb||%Zn|
|7047||From||To||M||ZnEq (%)||g/t Ag||%Pb||%Zn|
|7052||From||To||M||ZnEq (%)||g/t Ag||%Pb||%Zn|
|7052||From||To||M||ZnEq (%)||g/t Ag||%Pb||%Zn|
|7055A||From||To||M||ZnEq (%)||g/t Ag||%Pb||%Zn|
|7061||From||To||M||ZnEq (%)||g/t Ag||%Pb||%Zn|
|7046||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
|7052||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
|7052||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
|7054||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
|7054||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
|7055A||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
|7064||From||To||M||AgEq g/t||g/t Ag||%Pb||%Zn|
*Due to poor recovery and for QA/QC purposes in portions of holes 7054, 7056 and 7063 and for QA/QC purposes, the company chose to report assay results based only on recovered footage. Drilled footage is NOT the reported width of the intercepts.
(Reported widths are intercepted ore lengths and not true widths, as relationships with intercepted structures and contacts vary. Prices used to calculate Ag and Zn Eq are as follows: Zn=$1.16/lb, Pb=$0.92/lb, Ag=$20/oz.)
Alliance Global Partners (A.G.P) Mining Series Fireside Chat
March 23, 2021 @ 8:00am PT / 11:00am ET
Join Us: REGISTER NOW
Mining & Money Online Connect
March 24, 2021 @ 10:00am PT / 1:00pm ET
Join Us: REGISTER NOW
The diamond drilling program used HQ-size core. Bunker Hill followed standard QA/QC practices to ensure the integrity of the core and sample preparation through to delivery of the samples to the assay lab. The drill core was stored in a secure facility, photographed, logged and sampled based on lithologic and mineralogical interpretations. Standards of certified reference materials, field duplicates and blanks were inserted as samples shipped with the core samples to the lab.
ALS Global was used to provide analytical services and all results comply with both NI 43-101 and industry standards. ALS Global holds an industry standard ISO 17025 accreditation, specifying general requirements for laboratory performance.
The Company advises that it does not propose to base its production decision on a feasibility study of mineral reserves, demonstrating economic and technical viability, and, as a result, there may be an increased uncertainty of achieving any particular level of recovery of minerals or the cost of such recovery, including increased risks associated with developing a commercially mineable deposit. Historically, such projects have a higher risk of economic and technical failure. There is no guarantee that production will begin as anticipated or at all or that anticipated production costs will be achieved. The Company further cautions that a PEA is preliminary in nature. No mining study has been completed. Mineral resources are not mineral reserves and do not have demonstrated economic viability. There is no certainty that the PEA will be realized.
Mr. Scott E. Wilson, CPG, President of Resource Development Associates Inc. and a consultant to the Company, is an Independent “Qualified Person” as defined by NI 43-101 and is acting at the Qualified Person for the Company. He has reviewed and approved the technical information summarized in this news release.
